In the world of electronics manufacturing, laboratory research, and precision assembly, maintaining the integrity of sensitive components is paramount. Electrostatic discharge (ESD) can cause irreversible damage to printed circuit boards (PCBs) and other electronic parts, leading to significant financial losses and operational delays. Enter the SK47608 ESD PCB Trolley Storage System—a meticulously designed solution that combines robust materials, intelligent engineering, and ESD protection to meet the highest standards of safety and efficiency. With a storage capacity of 304 PCBs and designed for mobility and organization, this trolley system is an indispensable asset in any environment where static-sensitive materials are handled.
Product Basic Parameters
The SK47608 is built with precision and functionality in mind. Below are the detailed specifications:
Material: Constructed from 1.0mm thickness 202 stainless steel and PP plastic, ensuring durability, corrosion resistance, and ESD safety.
Overall Dimension (L x W x H): 550mm x 600mm x 1200mm, offering a compact yet high-capacity storage solution.
Hanging Basket Capacity: 8 pieces included.
Hanging Basket Size: Each basket measures 410mm x 280mm x 160mm.
Per Basket Storage: Each basket can hold up to 38 PCBs.
Total PCB Storage Capacity: 304 pieces.
Type: Vertical insertion type for secure and easy access.
Slot Specifications:
Slot depth: 5mm
Slot width: 2.8mm
Slot distance: 9.8mm
Slot length: 210mm
Wheels: Equipped with 4 pieces of 4-inch ESD rubber wheels for smooth and safe mobility.
Additional Features: Includes a conductive chain to ensure continuous grounding.
Surface Resistance: Maintains a surface resistance of 10^6–10^9Ω, providing optimal ESD protection.
Product Features:
Superior Material Composition: The use of 202 stainless steel and PP plastic ensures that the trolley is not only strong and long-lasting but also inherently anti-static.
These materials are chosen for their excellent mechanical properties and ESD-safe characteristics.
High-Capacity Storage: With a total capacity of 304 PCBs, this system maximizes space efficiency without compromising on accessibility.
The vertical insertion design allows for quick visual identification and retrieval of boards.
Enhanced Mobility: The four 4-inch ESD rubber wheels enable effortless movement across different floor types while maintaining grounding integrity.
This is especially useful in large facilities where components need to be transported between workstations.
Secure ESD Protection: The conductive chain and controlled surface resistance (10^6–10^9Ω) ensure that any static charge is safely dissipated,
protecting sensitive components from potential damage.
Modular and Scalable Design: The eight removable hanging baskets offer flexibility in organizing different types of PCBs.
Users can customize storage based on board size, project requirements, or frequency of use.
Durable and Low Maintenance: The stainless steel frame resists rust and wear,
while the PP plastic baskets are easy to clean and maintain, making this system suitable for demanding environments.
Product Function and Uses
The primary function of the SK47608 ESD PCB Trolley is to provide a safe, organized, and mobile storage solution
for electrostatic discharge-sensitive items, particularly printed circuit boards. It serves multiple roles:
Protection:
Safeguards PCBs from ESD, physical damage, and environmental contaminants during storage or transport.
Organization: Keeps boards neatly separated and easily accessible, reducing time spent searching for specific components and minimizing handling errors.
Transportation:Allows operators to move multiple boards securely from one location to another—for example, from storage areas to assembly lines or testing stations.
Workflow Integration:
Fits seamlessly into existing ESD-protected areas (EPAs), supporting continuous grounding protocols and enhancing overall workflow efficiency.
Product Application Fields
The versatility and reliability of the SK47608 ESD PCB Trolley make it an essential tool across
a wide range of industries where static-sensitive components are prevalent. Below are the key application fields:
Electronics Manufacturing:
In PCB assembly plants, this trolley is used to store and transport boards between solder paste application,
component placement, reflow soldering, and inspection stages.
Its ESD-safe properties ensure that boards remain undamaged throughout the production process.
Telecommunications Equipment Production:
Telecommunication devices often involve high-density PCBs that are extremely vulnerable to ESD.
This trolley provides a safe storage environment during manufacturing and testing phases.
Automotive Electronics:
The automotive industry relies on increasingly complex electronic systems.
From engine control units to infotainment systems, the SK47608 helps maintain the integrity of PCBs during assembly and logistics.
Aerospace and Defense:
In these sectors, reliability is non-negotiable. This trolley is used to handle critical PCBs for avionics,
navigation systems, and communication devices, ensuring compliance with stringent ESD standards.
Medical Device Manufacturing:
Medical electronics, such as diagnostic equipment and patient monitoring systems,
require the highest level of protection against static discharge. This system offers a safe storage solution that meets industry regulations.
Research and Development Laboratories:
R&D labs often prototype and test new PCB designs.
The trolley’s mobility and organization capabilities support iterative development processes while preventing E-related failures.
Consumer Electronics Production: From smartphones to wearable technology, consumer electronics manufacturers benefit from the efficient
and safe storage of high-volume PCB inventories.
Repair and Maintenance Facilities: Service centers use the trolley to organize and transport PCBs for repair,
ensuring that components are protected from further damage during handling.
In conclusion, the SK47608 ESD PCB Trolley Storage System is more than just a storage unit
—it is a comprehensive solution for enhancing productivity, ensuring safety, and maintaining organization in any static-sensitive environment.
Its robust design, combined with its extensive application across critical industries,
makes it a valuable investment for anyone serious about quality and efficiency in electronic component management.
